AQA Series Scroll Compressors
In Stock
50/60Hz
| Frequency | Voltage | Model | Cooling Capacity | Input | EER | COP | |
|---|---|---|---|---|---|---|---|
| Btu/hr | Watts | Watts | Btu/W.hr | W/W | |||
| 50Hz | 1Φ, 220/240V | AQA028PA | 23,265 | 6,819 | 2,557 | 9.1 | 2.67 |
| 50Hz | 1Φ, 220/240V | AQA036PA | 29,700 | 8,705 | 3,264 | 9.1 | 2.67 |
| 50Hz | 1Φ, 220/240V | AQA042PA | 34,403 | 10,083 | 3,781 | 9.1 | 2.67 |
| 60Hz | 1Φ, 220/240V | AQA034KA | 34,100 | 9,994 | 3,410 | 10.0 | 2.93 |
| 60Hz | 1Φ, 220/240V | AQA036KA | 36,000 | 10,551 | 3,462 | 10.4 | 3.05 |
| 60Hz | 1Φ, 220/240V | AQA038KA | 37,700 | 11,049 | 3,625 | 10.4 | 3.05 |
| 60Hz | 1Φ, 220/240V | AQA039KA | 39,000 | 11,430 | 3,750 | 10.4 | 3.05 |
| 60Hz | 1Φ, 220/240V | AQA040KA | 40,000 | 11,723 | 3,846 | 10.4 | 3.05 |
| 60Hz | 1Φ, 220/240V | AQA042KA | 41,500 | 12,163 | 3,952 | 10.5 | 3.08 |
| 60Hz | 3Φ, 208-230V | AQA042RA | 41,500 | 12,163 | 3,952 | 10.5 | 3.08 |
| 60Hz | 3Φ, 208-230V | AQA042RA | 41,500 | 12,163 | 3,952 | 10.5 | 3.08 |
| 60Hz | 3Φ, 575V | AQA042TA | 41,500 | 12,163 | 3,952 | 10.5 | 3.08 |
| 60Hz | 3Φ, 575V | AQA042TA | 41,500 | 12,163 | 3,952 | 10.5 | 3.08 |
| 50/60Hz | 3Φ, 380/420V, 50Hz/ 3Φ, 460V, 60Hz | AQA042WA | 32,300 / 41,500 | 9,467 / 12,163 | 3,365 / 3,952 | 9.6 / 10.5 | 2.81 / 3.08 |
